Weight (Including Battery And Propellers)

1280 g

Diagonal Size (Including Propellers)

689 mm

Max Ascent Speed

5 m/s

Max Descent Speed

3 m/s

Hover Accuracy

• Vertical: +/- 10cm
• Horizontal: +/- 1m

Max Speed

16 m/s (ATTI mode, no wind)

Max Altitude Above Sea Level

6000 m

Operating Temperature

0°C to 40°C

GPS Mode

GPS/GLONASS

Sensor

Sony EXMOR 1/2.3” Effective pixels: 12.4 M (total pixels: 12.76 M)

Lens

FOV 94° 20 mm (35 mm format equivalent) f/2.8, focus at ∞

ISO Range

100-3200 (video) 100-1600 (photo)

Shutter Speed

8s -1/8000s

Image Max Size

4000 x 3000

Still Photography Modes

• Single Shot
• Burst Shooting: 3/5/7 shots
• Auto Exposure Bracketing (AEB): 3/5
• Bracketed Frames at 0.7EV Bias
• Time-lapse

Video Recording Modes

Phantom 3 Professional

• UHD: 4096x2160p 24/25, 3840x2160p 24/25/30
• FHD: 1920x1080p 24/25/30/48/50/60
• HD: 1280x720p 24/25/30/48/50/60

Phantom 3 Advanced

• FHD: 1920x1080p 24/25/30/48/50/60
• HD: 1280x720p 24/25/30/48/50/60

Supported SD Card Types

Micro SD
Max capacity: 64 GB. Class 10 or UHS-1 rating required

Max Bitrate Of Video Storage

60 Mbps

Supported File Formats

• FAT32/exFAT
• Photo: JPEG, DNG
• Video: MP4, MOV (MPEG-4 AVC/H.264)

Operating Temperature

0°C to 40°C

Controllable Range

Pitch -90° to +30°

Stabilization

3-axis (pitch, roll, yaw)

Max Velocity

Less than 8 m/s (when 2 m above ground)

Altitude Range

30 cm-300 cm

Operating Range

30 cm-300 cm

Operating Environment

Surface with clear pattern and adequate lighting (Lux > 15)

Operating Frequency

2.400 GHz-2.483 GHz

Max Distance

2000m (outdoors and unobstructed)

Video Output Port

USB

Operating Temperature

0°C- 40°C

Battery

6000 mAh LiPo 2S

Mobile Device Holder

For tablet or phone

Receiver Sensitivity (1%PER)

101 dBm ±2 dBm

Transmitter Power (EIRP)

• FCC: 20 dBm
• CE: 16 dBm

Working Voltage

1.2 A @7.4 V

Voltage

17.4 V

Rated Power

Phantom 3 Professional

• 100 W

Phantom 3 Advanced

• 57 W

Capacity

4480 mAh

Voltage

15.2 V

Battery Type

LiPo 4S

Energy

68 Wh

Net Weight

365 g

Max Flight Time

Approximately 23 minutes

Operating Temperature

-10°C to 40°C

Max Charging Power

100 W

Mobile App

DJI Pilot

EIRP

100mW

Live View Working Frequency

2.4GHz ISM

Live View Quality

720P @ 30fps (depending on conditions and mobile device)

Latency

220ms (depending on conditions and mobile device)

Required Operating Systems

• iOS 8.0 or later
• Android 4.1.2 or later

Recommended Devices

• iOS: iPhone 5s, iPhone 6, iPhone 6 Plus, iPad Air, iPad Air Wi-Fi + Cellular, iPad mini 2, iPad mini 2 Wi-Fi + Cellular, iPad Air 2, iPad Air 2 Wi-Fi + Cellular, iPad mini 3, and iPad mini 3 Wi-Fi + Cellular. This app is optimized for iPhone 5s, iPhone 6, and iPhone 6 Plus
• Android: Samsung S5, Note 3, Sony Z3 EXPERIA, Google Nexus 7 II, Google Nexus 9, Mi 3, Nubia Z7 mini
• *Support for additional Android devices available as testing and development continues
